    1T/H Biomass Pellet Making Machine Wood Pellet Production Line For Bamboo , Peanut Shell

    Ask Lasest Price
    Model Number : Pellet line
    Certification : CE
    Price : USD10000~USD50000
    Payment Terms : T/T, L/C, Western Union, Paypal
    Supply Ability : 5 set per month
    Delivery Time : 25-30 days
    • Product Details
    • Company Profile

    1T/H Biomass Pellet Making Machine Wood Pellet Production Line For Bamboo , Peanut Shell

    1000KG/H capacity biomass pellets making line
    Capacity:
    1000KG/H

    Function:
    The complete line is used for making wood, straw, cotton stalk, rice husk, peanut shell, bamboo, empty fruit branch, pulverized coal and waste paper, etc. into pellets.


    Feature:
    Compact structure, scientific and reasonable design, durable operation, and simple maintenance.

    Technical parameter:

    ProcessCommodityMotorPowerStructural component
    Crushing1. Multi-function crusherMain motor45KW1. Crusher
    2. Draught fan
    3. Cyclone
    4. Air-lock valve
    5. Dust collector
    6. Elect cabinet
    Draught fan motor4KW
    Air-lock valve motor1.1KW
    Drying2. Drum dryerInput belt conveyor motor1.5KW1. Air-heating furnace
    2. In-feed belt conveyor
    3. Input air lock
    4. Rotary drum
    5. Speed reducer
    6. Blower with cyclone
    7. Output air lock
    8. Out-feed belt conveyor
    9. Elect-cabinet
    Input air-lock motor0.75KW
    Speed reducer motor5.5KW
    Blower motor5.5KW
    Output air-lock motor0.75KW
    Ouput belt conveyor motor0.75KW
    Pelleting3. 8m Belt ConveyerMain motor1.1KW1. Belt conveyor
    2. magnetic metal screener
    4. Ring die wood pellet mill 450-75Main motor75KW1. Feeding system
    2. Pellet machine
    3. Automatic lubricate machine
    4. Gearbox
    Feeder motor1.5KW
    Dial tray motor1.5KW
    Gearbox motor0.55KW
    Lubrication machine motor1.5KW
    Cooling5. 6m Belt ConveyerMain motor1.1KW1. Belt conveyor
    2. Small dustpans
    6. Cooling seperatorDraught fan motor5.5KW1. Feeding system
    2. Cooling system
    3. Vibration screening syestem
    4. Draught fan
    5. Cyclone
    Control feeding motor1.5KW
    Vibration motor1.1KW

    Detailed info. for every machine

    1. Multi-function crusher: It can crush your materials into powders, the materials after crushing, length will be less than 10mm.

    2. Drum dryer: t can reduce the moisture content of the wood sawdust into a suitable level.

    3. 3. 8m Belt Conveyer: it can transport the wood sawdust into feeder of pellet machine.

    4. Ring die pellet making machine 450-37: it can press your crushed materials into pellets.
